Illustrations are for reference only. Technical specifications may vary and are subject to change without notice.
Spiral – cable screw gland with suitable locknut, grey 20 x 1,5
Art.-Nr.
50082
Do you need help?
Directly to the contact form
Product information "Spiral – cable screw gland with suitable locknut, grey 20 x 1,5"
- material: polyamide
- protection spec.: IP 67
- temperature resistance: continious use -20 °C up to +80 °C
| A | 24 mm |
|---|---|
| Brand | HP-ECO® |
| C | 27 mm |
| Colour | gray |
| GL | 9 mm |
| Material | Polyamide |
| Protection spec. | IP 67 |
| Temperature resistant | -20 °C – 80 °C |
| Thread (AG) | M 20 x 1,5 |
| Thread type | metric |
| Type of packaging | 25 |
| Version | with locknut |
| b | 24 mm |
| min. - max. cable diameter | 7 - 13 mm |
