Illustrations are for reference only. Technical specifications may vary and are subject to change without notice.
Solderless Terminal spadetype, tin-plated C 5 - 10, 500 pcs.
Art.-Nr.
01230
Do you need help?
Directly to the contact form
Product information "Solderless Terminal spadetype, tin-plated C 5 - 10, 500 pcs."
- corresponding dimensions in conductor connection area 6mm² acc. to DIN 46234
- material: E-Cu
- surface: tin-plated
| A | 8,5 mm |
|---|---|
| DIN | DIN 46234 |
| Material | E-Cu |
| Nominal cross section | 10 mm² |
| Nominal size | C - 5 - 10 DIN |
| Type of packaging | 500 |
| Version | soldered, without insulation |
| b | 11 mm |
| d1 | 4,3 mm |
| d2 | 5,3 mm |
| l | 17 mm |
| s | 1,2 mm |
