preinsulated Wire End Sleeve for short-circuit proof cables NSGAFÖU, 2,50 HL blue
Art.-Nr.
09319
Do you need help?
Directly to the contact form
Product information "preinsulated Wire End Sleeve for short-circuit proof cables NSGAFÖU, 2,50 HL blue"
Special design with big insulation for all short circuit proof cables. Used for connections in switchgears and distribution boards, rail vehicles, solar systems, ignition cables, etc..
- material: E-Cu, tin plated
- plastic: polyamide
- temperature range: up to max. 120 °C
- long time: 105 °C
- zero halogen
| AWG | 14 |
|---|---|
| Application area | for short-circuit-proof cables |
| Colour | blue |
| Identifying Colour | DIN |
| Insulation material | Polypropylene |
| Insulation material properties | halogen-free |
| Length | Half-length |
| Material | E-Cu |
| Nominal cross section | 2,50 HL mm² |
| S1 | 0,15 mm |
| S2 | 0,30 mm |
| Temperature resistant | ≤ 105 °C |
| Type of packaging | 100 |
| Version | with insulation |
| d1 | 2,30 mm |
| d3 | 7,9 mm |
| l1 | 21 mm |
| l2 | 12,0 mm |
| material properties | galvanically tin-plated |
