Kabelverbinder IP68 3-polig wasserdicht 9A 450 V/AC Verbindungsmuffe für Erdkabel M12 0,5-0,75mm²
Art.-Nr.
55682-1
Do you need help?
Directly to the contact form
Product information "Kabelverbinder IP68 3-polig wasserdicht 9A 450 V/AC Verbindungsmuffe für Erdkabel M12 0,5-0,75mm²"
| Amperage | 9 A |
|---|---|
| Cable gland | M12 |
| Certificates | RoHS |
| Clamping range | 5 – 7,5 mm |
| Conductor cross section | 0.5 - 0.75 / screw connections mm² |
| Contacts | Tin-plated for rust prevention |
| Diameter | 20 mm |
| Length | 72 mm |
| Material | high-quality nylon PA66 |
| Number of openings | 2 |
| Pole | 3 |
| Type of packaging | 1 |
| Voltage AC | 450 V |
| incl. connection terminal | Ja |
