Illustrations are for reference only. Technical specifications may vary and are subject to change without notice.
HP VENT-LINE cable gland, stainless steel, M 16 x 1,5
Art.-Nr.
57016
Do you need help?
Directly to the contact form
Product information "HP VENT-LINE cable gland, stainless steel, M 16 x 1,5"
- material: cable gland: brass nickel-plated, stainless steel, polyamide
- seal: EPDM
- membrane: ePTFE
- protection class: IP 68 to 0,6 bar (to EN 60 529)
- temperature range: -40 °C up to 100 °C, temporarily up to approx. +120 °C
| E1 | 22 mm |
|---|---|
| Material | Stainless steel |
| Protection spec. | IP 68 |
| SW | 20 mm |
| TL | 34 - 42 mm |
| Temperature resistant | -40 °C – 100 °C |
| Thread (AG) | M 16 x 1,5 |
| Thread type | metric |
| Type of packaging | 1 |
| l | 6 mm |
| min. - max. cable diameter | 4,5 - 10 mm |
