Illustrations are for reference only. Technical specifications may vary and are subject to change without notice.
HP-FIXIT® Wire Holder with Push Mount, Polyamide 6,6, UL V-2, 35 x 28
Art.-Nr.
06517
Do you need help?
Directly to the contact form
Product information "HP-FIXIT® Wire Holder with Push Mount, Polyamide 6,6, UL V-2, 35 x 28"
- material: polyamid 6.6 according to UL 94 V-2
- temperature resistant: -40 °C up to +80 °C
| A | 35,8 mm |
|---|---|
| C | 31,1 mm |
| Colour | nature |
| D | 5,5 mm |
| Material | Polyamide 6.6, UL 94 V-2 |
| Mounting hole Ø | 4,8 mm |
| Panel thickness | 2 mm |
| Temperature resistant | -40 °C – 80 °C |
| Type of packaging | 100 |
| Version | with plug-in base |
| W1 | 11 mm |
| b | 28 mm |
