Illustrations are for reference only. Technical specifications may vary and are subject to change without notice.
HP-FIXIT® Cable Tie Socket with Push Mount, Polyamid 6,6 UL, 94 V-2, 8 mm
Art.-Nr.
06854
Do you need help?
Directly to the contact form
Product information "HP-FIXIT® Cable Tie Socket with Push Mount, Polyamid 6,6 UL, 94 V-2, 8 mm"
- material: Polyamide 6.6 according to UL 94 V-2
- temperature resistant: -40 °C up to +80 °C
| A | 10 mm |
|---|---|
| C | 7,7 mm |
| Cable Ties max. | 8 mm |
| Colour | nature |
| D | 8 mm |
| Material | Polyamide 6,6 |
| Mounting hole Ø | 6,5 mm |
| Panel thickness | 3 mm |
| Temperature resistant | -40 °C – 80 °C |
| Type of packaging | 100 |
| Version | with plug-in base |
| b | 10,6 mm |
| e | 3 mm |
| f | 8,1 mm |
