HIL-SHRINK® ECE 3:1 Heat Shrinkable Tubing, heavy wall with end caps 55,0/25,0 black
Art.-Nr.
34540
Do you need help?
Directly to the contact form
Product information "HIL-SHRINK® ECE 3:1 Heat Shrinkable Tubing, heavy wall with end caps 55,0/25,0 black"
Adhesive lined heatshrinkable cable breakouts
- permanent operating temperature: -30 °C up to +70 °C
- material: polyolefin cross-linked
- shrink temperature: +120 °C
Further Information:
- flame retardant
| Cable diameter | 25 - 49 mm |
|---|---|
| Colour | black |
| Continuous operating temperature | -30 °C – 70 °C |
| Flexibility | thick-walled |
| Length L | 145 mm |
| Material | Polyolefin radiation cross-linked |
| Shrinking temperature | 120 °C |
| Shrink ratio | 3:1 |
| Type of packaging | 10 |
| material properties | flame retardant, stiff |
| max after shrink operation Ø d | 26 mm |
| min. at delivery Ø D | 55 mm |
