Illustrations are for reference only. Technical specifications may vary and are subject to change without notice.
HIL-SHRINK® 3:1 CCB Heat Shrinkable TubingAdhesive lined heat shrinkable cable breakouts. Flame retardant 30,0/12 black
Art.-Nr.
34610
Do you need help?
Directly to the contact form
Product information "HIL-SHRINK® 3:1 CCB Heat Shrinkable TubingAdhesive lined heat shrinkable cable breakouts. Flame retardant 30,0/12 black"
Adhesive lined heatshrinkable cable breakouts
- permanent operating temperature: -30 °C up to +70 °C
- material: polyolefin cross-linked
- shrink temperature: +120 °C
Further Information:
- flame retardant
| Colour | black |
|---|---|
| Continuous operating temperature | -30 °C – 70 °C |
| Delivery condition L | 68 mm |
| Flexibility | thick-walled |
| Material | Polyolefin radiation cross-linked |
| Number of Piggyback Adapters | 2 |
| Shrinking temperature | 120 °C |
| Shrink ratio | 3:1 |
| Type of packaging | 10 |
| after shrinking L | 90 mm |
| material properties | flame retardant, stiff |
| max after shrink operation Ø D1 | 10 mm |
| max after shrink operation Ø D2 | 3 mm |
| min. at delivery Ø D1 | 30 mm |
| min. at delivery Ø D2 | 12 mm |
