Illustrations are for reference only. Technical specifications may vary and are subject to change without notice.
HIL-QUICK® Ring Terminal, insulated, Polycarbonate unbrazed, A 5 - 2,5, 1000 pcs.
Art.-Nr.
10013 SQ
Do you need help?
Directly to the contact form
Product information "HIL-QUICK® Ring Terminal, insulated, Polycarbonate unbrazed, A 5 - 2,5, 1000 pcs."
- with flared insulation
- suitable for harmonised lines
- insulation: polycarbonate unbrazed
- temperature range: -10 °C up to 105 °C
- zero halogen
- no silicone
| Brand | Hil-Quick® |
|---|---|
| Colour | blue |
| Insulation material | Polycarbonate |
| Material thickness | 0,8 mm |
| Nominal cross section | > 1 - 2,5 mm² |
| Nominal size | A - 5 - 2,5 DIN |
| Type of packaging | 1000 |
| Version | unsoldered |
| a1 | 5 mm |
| a2 | 11,3 mm |
| d2 | 5,3 mm |
| d3 | 10 mm |
| d4 | 5 mm |
| l | 20,3 mm |
