HIL-QUICK® Ring Terminal, insulated, Polycarbonate, A 6 - 6,0, 1000 pcs.
Art.-Nr.
10022 HQ
Do you need help?
Directly to the contact form
Product information "HIL-QUICK® Ring Terminal, insulated, Polycarbonate, A 6 - 6,0, 1000 pcs."
- acc. to DIN 46237
- with flared insulation
- suitable for harmonized wires
- insulation: polycarbonate
- temperature range: -10 °C up to +105 °C
- zero halogen
- no silicone
| Brand | Hil-Quick® |
|---|---|
| Colour | yellow |
| DIN | DIN 46237 |
| Insulation material | Polycarbonate |
| Material thickness | 1 mm |
| Nominal cross section | > 2,5 - 6 mm² |
| Nominal size | A - 6 - 6,0 DIN |
| Type of packaging | 1000 |
| Version | soldered |
| a1 | 6 mm |
| a2 | 14,15 mm |
| d2 | 6,5 mm |
| d3 | 11 mm |
| d4 | 6,5 mm |
| l | 24,15 mm |
