Illustrations are for reference only. Technical specifications may vary and are subject to change without notice.
HIL-QUICK® Female Push on Terminal, insulated piggyback, Polycarbonate, 6,3 - 0,8 - 2,5, 1000 pcs.
Art.-Nr.
10325 HQ
Do you need help?
Directly to the contact form
Product information "HIL-QUICK® Female Push on Terminal, insulated piggyback, Polycarbonate, 6,3 - 0,8 - 2,5, 1000 pcs."
- piggyback adaptors
- insulation: polycarbonate
- temperature range: -10 °C up to +105 °C
- zero halogen
| Colour | blue |
|---|---|
| Insulation material | Polycarbonate |
| Insulation material properties | halogen-free |
| Material | Brass |
| Material thickness | 0,4 mm |
| Nominal cross section | > 1 - 2,5 mm² |
| Nominal size | 2,5 mm² |
| Temperature resistant | -10 °C – 105 °C |
| Terminal Thickness | 0,8 mm |
| Terminal Width | 6,3 mm |
| Type of packaging | 1000 |
| Version | with metallic insulation support |
| a2 | 10 mm |
| l | 22 mm |
| l1 | 7,5 mm |
| l2 | 8 mm |
