Illustrations are for reference only. Technical specifications may vary and are subject to change without notice.
HIL-QUICK® Blade Terminal, insulated, PVC, 1,0 red, 10 mm long, 1000 pcs.
Art.-Nr.
10100 F1
Do you need help?
Directly to the contact form
Product information "HIL-QUICK® Blade Terminal, insulated, PVC, 1,0 red, 10 mm long, 1000 pcs."
- insulation: PVC
- temperature range: -10 °C up to +70 °C
| Colour | red |
|---|---|
| Insulation material | PVC |
| Material thickness | 0,75 mm |
| Nominal cross section | 0,5 - 1,5 mm² |
| Nominal size | 10 - 1 |
| Temperature resistant | -10 °C – 70 °C |
| Type of packaging | 1000 |
| a2 | 10 mm |
| d1 | 1,7 mm |
| d3 | 2,3 mm |
| d4 | 3,4 mm |
| l | 20 mm |
| l1 | 10 mm |
