Illustrations are for reference only. Technical specifications may vary and are subject to change without notice.
Female Push on Terminal, tin-plated, > 1 - 2,5, 1000 pcs.
Art.-Nr.
45312.123.211
Do you need help?
Directly to the contact form
Product information "Female Push on Terminal, tin-plated, > 1 - 2,5, 1000 pcs."
- non insulated
- DIN 46257, part 1 and similar
- material: brass
- surface: brass bare (MS) or tin-plated (VZ)
| Material | Brass |
|---|---|
| Material thickness | 0,35 mm |
| Nominal cross section | > 1 - 2,5 mm² |
| Nominal size | 4,8 - 2,5 DIN |
| Terminal Thickness | 0,8 mm |
| Terminal Width | 4,8 mm |
| Type of packaging | 1000 |
| Version | without insulation |
| a1 | 6,0 mm |
| a2 | 3,4 mm |
| l1 | 15,0 mm |
| l2 | 6,0 mm |
| l3 | 3,8 mm |
