Female Push on Terminal, brass bare, 0,5 - 1,5, 1000 pcs.
Art.-Nr.
45039.123.204
Do you need help?
Directly to the contact form
Product information "Female Push on Terminal, brass bare, 0,5 - 1,5, 1000 pcs."
- non insulated
- flag-type
- material: brass
- surface: brass bare (MS) or tin-plated (VZ)
| Design | C |
|---|---|
| Material | Brass |
| Material thickness | 0,45 mm |
| Nominal cross section | 0,5 - 1,5 mm² |
| Terminal Thickness | 0,8 mm |
| Terminal Width | 6,3 mm |
| Type of packaging | 1000 |
| a1 | 7,5 mm |
| a2 | 4,0 mm |
| l1 | 11 mm |
| l2 | 7,4 mm |
| l3 | 4,0 mm |
