Illustrations are for reference only. Technical specifications may vary and are subject to change without notice.
Cable Screw Glands, metric, M 40 x 1,5 - PG 36
Art.-Nr.
50297
Do you need help?
Directly to the contact form
Product information "Cable Screw Glands, metric, M 40 x 1,5 - PG 36"
- with hexagonal lowerpart
- material: brass, nickel-plated
- temperature resistance: -40 °C up to +70 °C
| GL | 10 mm |
|---|---|
| H | 79 mm |
| Inner connection thread | PG 36 |
| Material | Nickel-plated brass |
| Temperature resistant | -40 °C – 70 °C |
| Thread (AG) | M 40 x 1,5 |
| Thread type | metric |
| Type of packaging | 10 |
| Version | with hexagonal attachment on the intermediate socket |
| min. - max. cable diameter | 25,5 - 34 mm |
